Motor: 5 Horsepower & 3 Horsepower
Voltage: 230/460V, 3 Phase, 4 wire, 60Hz
Amperage: 50/30A
Controls: PLC
Height: 7' - 3''
Width: 5' - 10"
Length: 10' - 10"
Shipping Weight: 2,000 lbs
Output: up to 80lbs per hour1
Extrusion Size: 3-1/2" x 3-1/2"
Block Density: Adjustable 15-40 lbs per cubic ft.
Height: 6' - 4''
Width: 8' - 11"
Length: 4' - 11"
Shipping Weight: 2,500 lbs
Motor: 15 Horsepower
Voltage: 230/460V, 3 Phase, 4 wire, 60Hz
Amperage: 30/15A
Controls: PLC
Output: up to 150lbs per hour1
Extrusion Size: 3-1/2" x 3"
Block Density: Adjustable 15-40 lbs per cubic ft.
Height: 7' - 3''
Width: 12' - 5"
Length: 7' - 2"
Shipping Weight: 4,500 lbs
Motor: 20 Horsepower
Voltage: 230/460V, 3 Phase, 4 wire, 60Hz
Amperage: 54/27A
Controls: PLC
Ship up to 45,000 pounds on a 48 ft. trailer
Low cost continuous operation
Automatic or manual control
No banding or wires required
Automatic output density control
Heat-free process with no polymer degradation
Extruded material is small and easy to handle
Relatively small footprint
Output: up to 250lbs per hour1
Extrusion Size: 4-1/2" x 4"
Block Density: Adjustable 15-40 lbs per cubic ft.
Height: 7' - 3''
Width: 13' - 8"
Length: 7' - 3"
Shipping Weight: 5,000 lbs
Motor: 30 Horsepower
Voltage: 230/460V, 3 Phase, 4 wire, 60Hz
Amperage: 100/50A
Controls: PLC
Output: up to 500lbs per hour1
Extrusion Size: 4-1/2" x 4"
Block Density: Adjustable 15-40 lbs per cubic ft.
1 Depending on input foam density
PolyMax is celebrating its 20th anniversary of building recycling equipment. Our patented process is exclusively licensed to manufacture in the USA by Matrix Manufacturing (US patent no. 5,505,886).
